VT027 Pivotal Oscillation Plate
VT027 is a powerful pivotal oscillation plate that features an all-aluminum twin-coupler design, which greatly advances the performance and durability. Twin-coupler's compact design also allows this high-amplitude machine to be built in a thin body.
Also featured is a pair of detachable push-up bars incorporated with the oscillation plate for effective upper body exercise.
| Key Features | Motion Pattern |
|
 Pivotal Oscillation |
Index of Content Below
- Product Overview
- Tech Specs
- Push-up Bar Positions
- Advantage of Twin-Coupler
- Solid Steel Frame
- Fine Finish
- Jumping on the Floor (with video)
- Product Pictures
- Where to Purchase
1.Product Overview
What makes VT027 different is our patented aluminum alloy twin-coupler design that enhances the performance and durability.
Most other pivotal oscillation plates made by other manufacturers adopt traditional single-coupler that is made of nylon, which can reach material fatigue much sooner and fail the machine.
Our patented twin-coupler design also makes VT027 the thinnest pivotal oscillation plate that achieve 10mm amplitude on a decent size exercise surface area. The height of VT027 is only 4.5".
VT027 comes out as a rugged, vigorous pivotal oscillation plate built in a thin machine body, optimized for home use.
With confidence, we provide a straightforward 10 year warranty for VT027 pivotal oscillation plate. There will not be any out-of-pocket expense for customers for any warranty service.
2.Tech Specs
| Vibration Pattern | Pivotal Oscillation |
| Vibration Frequency Range | 5Hz ?C 14Hz in 20 levels |
| Max Vibration Amplitude | 10 mm |
| G-force | 0 - 2.51 |
| Power Supply | AC 110V-120V 60Hz |
| Motor | 200W PMDC motor |
| Machine Dimension | 630x400x115 mm 24.8x15.7x4.5 inch |
| Machine weight | 12.5 kg 27.5 kg |
| Package weight | 14.5 kg 32 lb |
| Max User Weight | 120 kg 264 lb |
3.Push-up Bars Positions
The detachable push-up bars can be plugged into four pairs of socket positions, each designed for exercising different muscle groups: chest muscles, shoulder muscles, back muscles, and triceps. Users can also creatively use the push-up bars for other upper-body exercises
VT027 Push-up Bar Positions
When not used, the push-up bars can be conveniently stored in their compartments at the backside of the machine. Pop-down caps are designed to cover the push-up bar sockets on the platform. When the push-up bars are not plugged in, the exercise plate surface is flat.
4.Advantage of Twin-Coupler
A planar four-bar linkage device is the core component of a pivotal oscillation plate. Such a four bar device transfers motor rotation to see-saw oscillation. The coupler bar is the most stress-prone part of a four-bar linkage device
Other manufacturers adopt a sandwich type construction for their coupler bars. Such a construction comprises a nylon main body at the middle and two sheet metal brackets screwed on the two sides. The benefit of such a design is that nylon's flexibility lowered the threshold for parts and assembly precision requirements, and therefore lowered the manufacturing cost. The needed strength for the coupler bar is made up by the sheet metal brackets screwed on the nylon body.
The drawback of such a design is that the nylon bar tends to reach material fatigue faster. Repeated stress and deformation produced from the vibration can speed up the fatigue process of the nylon bar. This type of nylon couplers have shorter life span.
This is also the reason that pivotal oscillation plates are usually designed to run at lower oscillation frequency.
Our patented twin-coupler 4-bar linkage device makes a big difference. It is specially designed with two coupler bars made of aluminum alloy. The device is much more strong and durable due to the reduced stress and enhanced material strength.
The twin-coupler four-bar linkage device is small sized and still delivers the same up-and-down displacement (vibration amplitude). This allows a high performance pivotal oscillation plate built on a thin machine body.
Below is the comparison of our patented twin-coupler 4-bar device and a traditional single coupler 4-bar device.
| Patented VT027 Twin Coupler Design | Traditional Single Coupler Design |
|
|
|
|
|
5.Solid Steel Frame
The upper frame and the lower frame are both whole-piece welded thick steel parts. In our design, efforts are made to reduce the number of parts, and minimize the use of bolts and nuts. Less parts mean less assembly and less friction in the movement, making the machine more stable and less noisy.
6.Fine Finish
VT027 adopts a simple and clean design style. Its geometric fashion contour demonstrates the precision of the ABS injection mold that is used to form the shell of the machine. The smooth and even matte finish stresses the perfect shape. The thick elastic coating is comfortable to touch and long lasting.
Jumping on the Floor at High Frequency
VT027 vibrates so vigorously that it can jump on the floor if there is no body weight on it. Please make sure you are on VT027 before you start the vibration.
Depending on the floor situation, machine jumping (if no body weight on the machine) usually happens when the speed level is above 16 ( above 12Hz frequency).
This problem actually demonstrate the vibration intensity that VT027 can achieves.
The video clip bellow demonstrates a no-load VT027 jumping on the floor running at high speed level.
Keep your body weight on the machine to prevent it from jumping.
The machine jumping, on the other hand, showcases the vibration intensity that VT027 can achieve.
If you want a powerful vibration plate, you have to deal with the issue of machine jumping on the floor, simply by standing on the machine before you start the vibration.
Putting a soft mat beneath the machine can create some friction and buffer between the machine and the floor, and ease or avoid the machine jumping problem.
7.Product Pictures
At the height of only 4.5 inch, VT027 is the shortest pivotal oscillation plate in the market that can achieve a 10 mm vibration amplitude on a decent size exercise plate.
VT027 - the thinnest vibration plate in the market
Our patented twin-coupler device allow us to build a powerful, strong and durable vibration plate in a thin machine body.
8.Where to Purchase
Purchase VT vibration plate from our VT Amazon Store or VT eStore, same terms and conditions.
- Free shipping to the 48 contiguous states in the US
- Free 90 day return for any reason for full refund, free return shipping
- 10 year warranty, no any out-of-pocket expense for any warranty service
- Exceptional customer service and lifetime support from a professional team that are passionate about vibration therapy and care about customers.
Purchase VT027 on Amazon
